交换机命令
~~~~~~~~~~
[Quidway]dis cur ；显示当前配置
[Quidway]display current-configuration ；显示当前配置
[Quidway]display interfaces ；显示接口信息
[Quidway]display vlan all ；显示路由信息
[Quidway]display version ；显示版本信息
[Quidway]super password ；修改特权用户密码
[Quidway]sysname ；交换机命名
[Quidway]interface ethernet 0/1 ；进入接口视图
[Quidway]interface vlan x ；进入接口视图
[Quidway-Vlan-interfacex]ip address 10.65.1.1 255.255.0.0 ；配置VLAN的IP地址
[Quidway]ip route-static 0.0.0.0 0.0.0.0 10.65.1.2 ；静态路由＝网关
[Quidway]rip ；三层交换支持
[Quidway]local-user ftp
[Quidway]user-interface vty 0 4 ；进入虚拟终端
[S3026-ui-vty0-4]authentication-mode password ；设置口令模式
[S3026-ui-vty0-4]set authentication-mode password simple 222 ；设置口令
[S3026-ui-vty0-4]user privilege level 3 ；用户级别
[Quidway]interface ethernet 0/1 ；进入端口模式
[Quidway]int e0/1 ；进入端口模式
[Quidway-Ethernet0/1]duplex {half|full|auto} ；配置端口工作状态
[Quidway-Ethernet0/1]speed {10|100|auto} ；配置端口工作速率
[Quidway-Ethernet0/1]flow-control ；配置端口流控
[Quidway-Ethernet0/1]mdi {across|auto|normal} ；配置端口平接扭接
[Quidway-Ethernet0/1]port link-type {trunk|access|hybrid} ；设置端口工作模式
[Quidway-Ethernet0/1]port access vlan 3 ；当前端口加入到VLAN
[Quidway-Ethernet0/2]port trunk permit vlan {ID|All} ；设trunk允许的VLAN
[Quidway-Ethernet0/3]port trunk pvid vlan 3 ；设置trunk端口的PVID
[Quidway-Ethernet0/1]undo shutdown ；激活端口
[Quidway-Ethernet0/1]shutdown ；关闭端口
[Quidway-Ethernet0/1]quit ；返回
[Quidway]vlan 3 ；创建VLAN
[Quidway-vlan3]port ethernet 0/1 ；在VLAN中增加端口
[Quidway-vlan3]port e0/1 ；简写方式
[Quidway-vlan3]port ethernet 0/1 to ethernet 0/4 ；在VLAN中增加端口
[Quidway-vlan3]port e0/1 to e0/4 ；简写方式
[Quidway]monitor-port <interface_type interface_num> ；指定镜像端口
[Quidway]port mirror <interface_type interface_num> ；指定被镜像端口
[Quidway]port mirror int_list observing-port int_type int_num ；指定镜像和被镜像
[Quidway]description string ；指定VLAN描述字符
[Quidway]description ；删除VLAN描述字符
[Quidway]display vlan [vlan_id] ；查看VLAN设置
[Quidway]stp {enable|disable} ；设置生成树,默认关闭
[Quidway]stp priority 4096 ；设置交换机的优先级
[Quidway]stp root
[Quidway-Ethernet0/1]stp cost 200 ；设置交换机端口的花费
[Quidway]link-aggregation e0/1 to e0/4 ingress|both ; 端口的聚合
[Quidway]undo link-aggregation e0/1|all ; 始端口为通道号
[SwitchA-vlanx]isolate-user-vlan enable ；设置主vlan
[SwitchA]isolate-user-vlan <x> secondary <list> ；设置主vlan包括的子vlan
[Quidway-Ethernet0/2]port hybrid pvid vlan <id> ；设置vlan的pvid
[Quidway-Ethernet0/2]port hybrid pvid ；删除vlan的pvid
[Quidway-Ethernet0/2]port hybrid vlan vlan_id_list untagged ；设置无标识的vlan
如果包的vlan id与PVId一致，则去掉vlan信息. 默认PVID=1。
所以设置PVID为所属vlan id, 设置可以互通的vlan为untagged.
－－－－－－－－－－－－－－－－－－－－－－－－－－－－－－－－－－－－－－－－
路由器命令
~~~~~~~~~~
[Quidway]display version ；显示版本信息
[Quidway]display current-configuration ；显示当前配置
[Quidway]display interfaces ；显示接口信息
[Quidway]display ip route ；显示路由信息
[Quidway]sysname aabbcc ；更改主机名
[Quidway]super passwrod 123456 ；设置口令
[Quidway]interface serial0 ；进入接口
[Quidway-serial0]ip address <ip> <mask|mask_len> ；配置端口IP地址
[Quidway-serial0]undo shutdown ；激活端口
[Quidway]link-protocol hdlc ；绑定hdlc协议
[Quidway]user-interface vty 0 4
[Quidway-ui-vty0-4]authentication-mode password
[Quidway-ui-vty0-4]set authentication-mode password simple 222
[Quidway-ui-vty0-4]user privilege level 3
[Quidway-ui-vty0-4]quit
[Quidway]debugging hdlc all serial0 ；显示所有信息
[Quidway]debugging hdlc event serial0 ；调试事件信息
[Quidway]debugging hdlc packet serial0 ；显示包的信息
静态路由：
[Quidway]ip route-static <ip><mask>{interface number|nexthop}[value][reject|blackhole]
例如：
[Quidway]ip route-static 129.1.0.0 16 10.0.0.2
[Quidway]ip route-static 129.1.0.0 255.255.0.0 10.0.0.2
[Quidway]ip route-static 129.1.0.0 16 Serial 2
[Quidway]ip route-static 0.0.0.0 0.0.0.0 10.0.0.2
动态路由：
[Quidway]rip ；设置动态路由
[Quidway]rip work ；设置工作允许
[Quidway]rip input ；设置入口允许
[Quidway]rip output ；设置出口允许
[Quidway-rip]network 1.0.0.0 ；设置交换路由网络
[Quidway-rip]network all ；设置与所有网络交换
[Quidway-rip]peer ip-address ；
[Quidway-rip]summary ；路由聚合
[Quidway]rip version 1 ；设置工作在版本1
[Quidway]rip version 2 multicast ；设版本2，多播方式
[Quidway-Ethernet0]rip split-horizon ；水平分隔
[Quidway]router id A.B.C.D ；配置路由器的ID
[Quidway]ospf enable ；启动OSPF协议
[Quidway-ospf]import-route direct ；引入直联路由
[Quidway-Serial0]ospf enable area <area_id> ；配置OSPF区域
标准访问列表命令格式如下：
acl <acl-number> [match-order config|auto] ；默认前者顺序匹配。
rule [normal|special] [source source-addr source-wildcard|any]
例：
[Quidway]acl 10
[Quidway-acl-10]rule normal permit source 10.0.0.0 0.0.0.255
[Quidway-acl-10]rule normal deny source any
扩展访问控制列表配置命令
配置TCP/UDP协议的扩展访问列表：
rule {normal|special}{tcp|udp}source {<ip wild>|any}destination <ip wild>|any}
[operate]
配置ICMP协议的扩展访问列表：
rule {normal|special}icmp source {<ip wild>|any]destination {<ip wild>|any]
[icmp-code] [logging]
扩展访问控制列表操作符的含义
equal portnumber ；等于
greater-than portnumber ；大于
less-than portnumber ；小于
not-equal portnumber ；不等
range portnumber1 portnumber2 ；区间
扩展访问控制列表举例
[Quidway]acl 101
[Quidway-acl-101]rule deny souce any destination any
[Quidway-acl-101]rule permit icmp source any destination any icmp-type echo
[Quidway-acl-101]rule permit icmp source any destination any icmp-type echo-reply
[Quidway]acl 102
[Quidway-acl-102]rule permit ip source 10.0.0.1 0.0.0.0 destination 202.0.0.1 0.0.0.0
[Quidway-acl-102]rule deny ip source any destination any
[Quidway]acl 103
[Quidway-acl-103]rule permit tcp source any destination 10.0.0.1 0.0.0.0 destination-port equal ftp
[Quidway-acl-103]rule permit tcp source any destination 10.0.0.2 0.0.0.0 destination-port equal www
[Quidway]firewall enable
[Quidway]firewall default permit|deny
[Quidway]int e0
[Quidway-Ethernet0]firewall packet-filter 101 inbound|outbound
地址转换配置举例
[Quidway]firewall enable
[Quidway]firewall default permit
[Quidway]acl 101 ;内部指定主机可以进入e0
[Quidway-acl-101]rule deny ip source any destination any
[Quidway-acl-101]rule permit ip source 129.38.1.1 0 destination any
[Quidway-acl-101]rule permit ip source 129.38.1.2 0 destination any
[Quidway-acl-101]rule permit ip source 129.38.1.3 0 destination any
[Quidway-acl-101]rule permit ip source 129.38.1.4 0 destination any
[Quidway-acl-101]quit
[Quidway]int e0
[Quidway-Ethernet0]firewall packet-filter 101 inbound
[Quidway]acl 102 ;外部特定主机和大于1024端口的数据包允许进入S0
[Quidway-acl-102]rule deny ip source any destination any
[Quidway-acl-102]rule permit tcp source 202.39.2.3 0 destination 202.38.160.1 0
[Quidway-acl-102]rule permit tcp source any destination 202.38.160.1 0 destination-port great-than
1024
[Quidway-acl-102]quit
[Quidway]int s0
[Quidway-Serial0]firewall packet-filter 102 inbound ；设202.38.160.1是路由器出口IP。
[Quidway-Serial0]nat outbound 101 interface ;是Easy ip，将acl 101允许的IP从本接口出时变换源地址。
内部服务器地址转换配置命令(静态nat)：
nat server global <ip> [port] inside <ip> port [protocol] ;global_port不写时使用inside_port
[Quidway-Serial0]nat server global 202.38.160.1 inside 129.38.1.1 ftp tcp
[Quidway-Serial0]nat server global 202.38.160.1 inside 129.38.1.2 telnet tcp
[Quidway-Serial0]nat server global 202.38.160.1 inside 129.38.1.3 www tcp
设有公网IP：202.38.160.101~202.38.160.103 可以使用。 ;对外访问(原例题)
[Quidway]nat address-group 202.38.160.101 202.38.160.103 pool1 ;建立地址池
[Quidway]acl 1
[Quidway-acl-1]rule permit source 10.110.10.0 0.0.0.255 ;指定允许的内部网络
[Quidway-acl-1]rule deny source any
[Quidway-acl-1]int serial 0
[Quidway-Serial0]nat outbound 1 address-group pool1 ;在s0口从地址池取出IP对外访问
[Quidway-Serial0]nat server global 202.38.160.101 inside 10.110.10.1 ftp tcp
[Quidway-Serial0]nat server global 202.38.160.102 inside 10.110.10.2 www tcp
[Quidway-Serial0]nat server global 202.38.160.102 8080 inside 10.110.10.3 www tcp
[Quidway-Serial0]nat server global 202.38.160.103 inside 10.110.10.4 smtp udp
PPP设置：
[Quidway-s0]link-protocol ppp ;默认的协议
PPP验证：
主验方：pap|chap
[Quidway]local-user q2 password {simple|cipher} hello ;路由器1
[Quidway]interface serial 0
[Quidway-serial0]ppp authentication-mode
[Quidway-serial0]ppp chap user q1 ;pap时，没有此句
pap被验方：
[Quidway]interface serial 0 ;路由器2
[Quidway-serial0]ppp pap local-user q2 password {simple|cipher} hello
chap被验方：
[Quidway]interface serial 0 ;路由器2
[Quidway-serial0]ppp chap user q2 ;自己路由器名
[Quidway-serial0]local-user q1 password {simple|cipher} hello ;对方路由器名
帧中继frame-relay (二分册6-61)
[q1]fr switching
[q1]int s1
[q1-Serial1]ip address 192.168.34.51 255.255.255.0
[q1-Serial1]link-protocol fr ;封装帧中继协议
[q1-Serial1]fr interface-type dce
[q1-Serial1]fr dlci 100
[q1-Serial1]fr inarp
[q1-Serial1]fr map ip 192.168.34.52 dlci 100
[q2]int s1
[q2-Serial1]ip address 192.168.34.52 255.255.255.0
[q2-Serial1]link-protocol fr
[q2-Serial1]fr interface-type dte
[q2-Serial1]fr dlci 100
[q2-Serial1]fr inarp
[q2-Serial1]fr map ip 192.168.34.51 dlci 100
帧中继监测
[q1]display fr lmi-info[]interface type number]
[q1]display fr map
[q1]display fr pvc-info[serial interface-number][dlci dlci-number]
[q1]display fr dlci-switch
[q1]display fr interface
[q1]reset fr inarp-info
[q1]debugging fr all[interface type number]
[q1]debugging fr arp[interface type number]
[q1]debugging fr event[interface type number]
[q1]debugging fr lmi[interface type number]
启动ftp服务：
[Quidway]local-user ftp password {simple|cipher} aaa service-type ftp
[Quidway]ftp server enable
